Production Facility



New Headquarters & Taoyuan Factory
(December, 2020)

Production Space: 104,141m2

Assembly Line: Module Line, Instrument & ATS Assembly Line, Mechatronics System Line

2022 Granted Certification of「Gold」Level Green Building

Taoyuan Huaya Factory

Production Space: 17,233 m2

Assembly Line: AI Line, SMT Line, PCBA Line, Module Line, Instrument & ATS Assembly Line

Kaohsiung Factory

Production Space: 13,469 m2

Assembly Line: Mechatronics System Line

Shenzhen Factory

Production Space: 35,500 ft2

Assembly Line: Module Assembly Line



Capital Equipment
SMT Line

Equipment:

  • Screen Printer
  • Adhesive Dispenser
  • Compact-Sized Chip Mounter
  • Compact-Sized Fine-Pitch Mounter
  • AOI Inspection
  • N2 Reflow Oven
  • PCB Size
    Line1: (Max) 750*460mm
    Line2: (Max) 460*360mm
  • Range of Component
    Line1: 0603(0201") Chip ~ Φ43mm ~ Φ150mm
    Line2: 0402 (01005") Chip ~ Φ74mm or 50x150mm
  • Placement tact time (Each M/C)
    Line1: Chip 18,000 CPH, IC 2,400 CPH
    LIne2: Chip 23,300 CPH, IC 4,860 CPH
  • Reflow
    Line1: 10 Heat Zones, 3 Cooling Zones
    Line2: 11 Heat Zones, 2 Cooling Zones
Al Line

Equipment:

  • Component Sequencer
  • Component Inserter
  • PCB Size: (Max) 480*400mm
  • Insertion rates: 25000 CPH
Inspection
  • Equipment: X-Ray
  • Maximum current: 1000uA
  • Detail detect ability: down to 1 micron
DIP Line
